200528-0060
Код товара: 10750697
Цена от:
49,89 руб.
Описание 200528-0060
Molex Easy-On 1.0mm FFC/FPC Connectors with Double-Bottom Contacts, 200528 Series Easy-On 1.0 mm FFC/FPC connectors with double-bottom contacts and a compact, low profile design with a mating height of just 1.90 mm. The contact design of these Easy-On 1.0 mm FFC/FPC connectors features 2 lower contacts per circuit. This double bottom contact terminal design removes dust and contaminants resulting in a clean mating interface and high contact reliability. This design also provides double the contacts per circuit. The actuators of these Easy-On 1.0 mm FFC/FPC connectors are pre-assembled covers that secure the connection between the FFC/FPC and the connector terminals. The housings of these FFC/FPC connectors feature a cable ear-tab locking feature with indents in them in which accept the FPC tabs. This feature provides proper cable seating and alignment, high retention force and easy actuation. These Easy-On 1.0 mm FFC/FPC connectors also have Zero insertion force for easy cable insertion and for allowing repeat cycling with minimum wear. The top of the housings also feature a vacuum pick and place area for easy board assembly and cost savings. Robust solder tabs on these SMT FFC/FPC connectors offer secure PCB retention and strain relief for solder joints. These Easy-On 1.0 mm FFC/FPC connectors are available in a wide range of circuit sizes for design flexibility.
Brand | Molex |
---|---|
Количество контактов | 6 |
Материал контактов | Фосфористая бронза |
Шаг | 1мм |
Тип монтажа | Поверхностный монтаж |
Тип соединителя | Вилка |
Тип оконцовки | Нижний контакт ZIF |
Ориентация корпуса | Прямой угол |
Номинальный ток | 500mA |
Номинальное напряжение | 50 V ac/dc |
Серия | Easy-On |
Номер серии | 200528 |
Количество рядов | 1 |
Покрытие контактов | Золото поверх никеля |
Метод оконцовки | Припой |
Минимальная рабочая температура | -40°C |
Максимальная рабочая температура | +105°C |
Материал корпуса | Жидкокристаллический полимер |
Страна происхождения | JP |
